Product Range
Please select from the list below for more detailed information
MICROseries
MICROseries range overview
MICROzone amplifier/controller
MULTIzone multi-zone controller
MICROplus 4-channel power amplifier
MICROdot ceiling speaker
MICROpoint wall-mount speaker
MICROline wall-mount speaker
MICROsub 3 active subwoofer
MEDIANseries
MEDIAtrac wall-mount speaker
Median IC 125 ceiling loudspeaker
Median IC 165 ceiling loudspeaker

Downloads
Please select from the list below to download brochures, specification sheets, photographs and further information
MICROseries and MEDIANseries
MICROseries
MEDIANseries

MICROseries is a system, not just a range of components. The system is DSP controlled via the MICROzone or MULTIzone to give outstanding audio performance from the MICROseries ultra-compact loudspeakers.

The MICROzone is a 5-configuration amplifier/controller that provides unique flexibility for single or multi-location input and control. Comprehensive switching functions enable the unit to be used singly or in multiples in various configurations.

For larger systems, the MULTIzone zone control mixer provides 4 zone outputs with 6 music inputs plus a microphone input for paging applications. Each of the 4 outputs can be independently configured to provide music from any one of the inputs plus the paging microphone. Remote zone control is possible via wired control panels or an RS232 interface. Up to 7 MULTIzone units can be linked (daisy-chained) for systems of up to 28 zones.

The MICROplus is a 4-channel power amplifier for use with either MICROzone or MULTIzone.

The MICROseries system offers the options of two wall-mount and one ceiling-mount loudspeaker, which give wide-band audio so that, no matter where you are in the room, the sound from the main loudspeakers remains coherent and pleasing. Integral wire-through brackets are incorporated and the loudspeaker enclosures are constructed from high quality aluminium. For many BGM and information installations no additional bass loudspeakers are required, but for applications requiring extended, higher SPL bass performance, the system is complete with the active MICROsub 3.

MICROzone
MICROplus
MULTIzone

The Median IC 125 and IC 165 from Audica Professional are premium ceiling loudspeakers designed for applications where high fidelity audio quality is a primary requirement. The open back design saves depth and weight for installations where a sealed enclosure (back-can) is not required.

Both models feature a swivel HF unit, to direct the sound to the required listening area, and incorporate an HF cut/boost control to shape the frequency response for the application or room acoustics.

The loudspeakers are quick to install with swing out legs for secure fitting and the ultra-low profile grille is magnetically mounted for a fast fit and a clean, discreet appearance.

Requiring no signal processing, the Median IC 125 and IC 165 loudspeakers are ideally suited for use in systems with the Audica Professional MULTIzone controller (EQ setting flat) and the MICROplus power amplifier.

Example Installations
MEDIANseries systems and combined MICROseries / MEDIANseries systems
Median loudspeakers mark a change for Audica Professional, in that they do not require the same Audica equalisation (AEQ) as MICROseries loudspeakers.
MEDIAtrac, Median IC125 and Median IC165 can be used for complete systems using the MULTIzone controller and MICROplus 4-channel amplifier.
As the  MULTIzone enables each zone output to be set for ‘AEQ’ (for the MICROdot, MICROpoint and MICROline) or ‘flat response’ (for the MEDIAtrac, Median IC125 and IC165), it can also be used for combining MICROseries and MEDIAN loudspeakers in systems.
The MULTIzone provides the solution for systems using MICROseries loudspeakers, MEDIANseries loudspeakers, or a combination of both.
The MULTIzone is a zone control mixer consisting of 4 zones with 6 music inputs plus a microphone input for paging applications. Each of the 4 outputs can be independently configured to provide music from any one of the inputs plus the paging microphone and the relative levels are set by front panel controls. The music is automatically reduced in level (ducking) to allow for announcements to be heard clearly. Each zone output is mono and all inputs are stereo capable (mixed to mono internally).
Remote zone control is possible via wired control panels or an RS232 interface. Up to 7 MULTIzone units can be linked (daisy-chained) for systems of up to 28 zones.

MEDIAtrac is a high quality loudspeaker for music, audio visual and speech applications, including retail outlets, bars and restaurants, hotels, education establishments, meeting rooms, museums and visitor centres.

The extruded aluminium body houses a 20mm dome high frequency unit, 4-inch bass unit and 4-inch passive bass radiator. The unit is designed for 8 Ohm low impedance and 100V line use, and is adjustable via a tap switch located discretely behind the removable front grille.

Finished in white, MEDIAtrac is supplied complete with an adjustable yoke bracket for fast and reliable installation.
