Future Media Systems Chooses Audica Professional for Wimborne Minster
A landmark building, the two towers of Wimborne Minster are seen from whichever direction
you approach the Dorset town of Wimborne. There has been a church on the site for
1,300 years,with the greater part of the architecturally significant Church we see
today being built by the Normans between 1120 and 1180. Its library is one of the
first public libraries in existence and is one of only four surviving chained libraries
in the world.
A flat panel loudspeakers system previously employed in the church did not intrude
on the buildings aesthetics, but its wide dispersion in the highly reverberant space
gave low perceived quality and Christchurch-based Future Media Systems was asked
to propose an alternative solution.
The brief was to design and install a system that would reproduce high quality speech
and light music throughout the whole church, yet be as visually discreet as possible.
The system needed to be simple to use, but with a full range of hidden control available.
Luke Siemaszko, Director of Future Media Systems, explained their approach, “Audica
Professional MICROpoint loudspeakers were a key feature in our winning bid. These
offered excellent sound quality from a very compact package with a minimally intrusive
appearance. We adopted a distributed approach, so that the room reverberation was
stimulated as little as possible, with the congregation hearing the highest possible
ratio of direct sound to reflected sound. To achieve this we used thirty-five MICROpoint
loudspeakers to cover the nave, aisles, two chapels, two transepts and the choir”.
The loudspeakers are wired in four zones, to allow for flexible use of the church,
with an Ecler MAP4/4000R 4-channel 2U amplifier providing good sound quality in an
elegant, space-saving solution. As cables could not be channelled into the buildings
fabric, to allow the use of thinner loudspeaker cables Future Media Systems wired
the system as high impedance, with custom-made matching transformers. An active subwoofer
enhances low frequency reproduction, principally for use when playing recorded organ
All mixing, eq, compression and automatic mixer function are provided by a Biamp
Nexia DSP and, for ease of control, Future Media Systems provided a fully customised
interface using a touch screen. One control page provides just a level meter, level
control and mute switch for each channel, to provide a simple interface for day to
day operation. An "advanced" control page is provided for more skilled operators
and this has controls for three band equalisation, input attention, and automatic
mixer function for each channel, plus zone level controls, mute switches and meters.
The system also provides compression on each channel, and graphic equalisers for
each output, but no user controls are provided for these to simplify the interface
and to prevent unauthorised adjustment.
The system has the advantage that it powers up into a known state, making life as
simple as possible for the operator. A Biamp Volume 8/Select 8 control panel by the
church door allows a verger to control some the channel levels and to recall scenes
from that position, without having to access the touch screen. This provides very
simple controls for services where the number of channels and features offered on
the touch screen are not required.
Sennheiser evolution radio microphones with active antennae and aerial distribution
provide faultless performance throughout the church, even in the crypt which is below
ground and under several feet of stone.
Siemaszko concludes, “The key components of the system from my perspective were the
MICROpoint loudspeakers, and the DSP and touchscreen for mixing and control. The
MICROpoint loudspeakers give excellent reproduction and a discreet appearance at
a reasonable price. We were required to fit the system without drilling into any
ancient stonework and the small size and weight of the MICROpoints allowed us to
do this easily as we could drill the fixings into the grout between masonry blocks.
Furthermore they were lovely to set up - the system eq is almost flat. We put in
a bit of cut at 230Hz to calm down a room resonance, and a bit of lift above 8kHz.
Otherwise it’s completely flat and the resulting sound quality is excellent”.
Members of Wimborne Minster congregations are agreed that they are now able to hear
speakers at the services with excellent clarity and the staff and volunteers are
finding the controls simple and straightforward to operate.
